Looking for some peace of mind with your electrical components in your van? Wondering what the right electrical components are? Don’t know what amperage of breaker to buy for a solar charge controller? Can’t find links to all the components you need? Look no further!
This spreadsheet has over 50 purchasable components (with accompanying links) to help guide you through your electrical component purchasing process; a process that can be extremely difficult and confusing.
This PDF gives you not only links to helpful products ranging from battery banks, a recommended battery isolator, solar charge controller, solar panels, inverter, but it also gives you links to the correctly rated fuses/breakers to purchase for each system. So not only are you purchasing a huge list of quality products to choose from, you know you are purchasing products that already work together.
We have also thrown in a few other items like suggested refrigerators, the best roof vent, water pump setup, diesel air heater, our favorite USB’s, and more!
When you purchase this product you also receive one free electrical email consultation. To use this, send your order number with “DIY Email Consultation” in the subject line, followed by the question you need to ask in the body of the email. Send this email to firstname.lastname@example.org.
Please be aware that THIS IS NOT AN INSTRUCTION BOOK FOR WIRING YOUR VAN. Its’ sole purpose is to provide all the necessary components for wiring a van correctly but does not provide wiring instructions.
DIY Camper Wiring Diagram
Introducing our DIY Camper Wiring Diagram! Tired of forums with no definitive answers? Tired of wiring diagrams that make absolutely no sense, or that were made for someone else’s van 3 years ago? Tired of little icons only electrical technicians understand? Look no further, we have the answers for you, and we use common English with words like “juice” to describe functionality!
This Camper Wiring Diagram simply lays out how to connect appliances like solar panels to a secondary battery, an inverter to a secondary battery, an air heater to a secondary battery, and much, much more. If you like in-depth explanations, zoom in close to read text describing the function of each component on the diagram. Get overwhelmed with too much text? Zoom out and you can get the big picture without distractions. Only wiring solar panels to a secondary battery and the other information is of no use to you? No worries! Each system can assembled separate of themselves with this diagram’s instruction. This is the most simple and fully functional wiring diagram for campers.
Tired of having to make 1000 different decisions about your electrical setup? Not a problem; we are a one stop shop! Purchase our “DIY Electrical Spreadsheet” in combination with our “DIY Camper Wiring Diagram” and almost every single question you could ever have about electricity in a camper will be answered. The best heaters, the best roof vents, the best water pump, the best and most accessible batteries, the most accessible fuses and fuse types, solar panels and charge controllers, inverters and instructions on how to wire them all up are now for sale on our website!
Let’s get your camper functional and on the ROAD! Yehaw!
Shopping for someone else but not sure what to give them? Give them the gift of choice.
Gift cards are delivered by email and contain instructions to redeem them at checkout. Our gift cards have no additional processing fees.
